Instantaneous Safety Gears
With one roller
With one roller
Type BP1 – BP2 – BP3 for guide from 5 to 9 mm, 10 mm and 16 mm. Approved by TÜV Germany according to Directive 95/16/EC and EN81-1/2 and 2014/33/EU directive and EN81-20/50.
| BP1 tripping speed (m/s) | BP1 load for guide 5 mm (kg) | BP1 load for guide 6-8 mm (kg) | BP1 load for guide 9 mm (kg) |
|---|---|---|---|
| 0.50 | 1769 | 1573 | 2564 |
| 0.60 | 1702 | 1513 | 2467 |
| 0.70 | 1630 | 1449 | 2362 |
| 0.80 | 1553 | 1381 | 2251 |
| 0.90 | 1474 | 1311 | 2137 |
| 1.00 | 1395 | 1241 | 2022 |
| 1.10 | 1318 | 1171 | 1910 |
| 1.20 | 1242 | 1104 | 1799 |
| 1.32 | 1154 | 1026 | 1673 |
| 1.65 | 940 | 835 | 1362 |
| BP2 tripping speed (m/s) | BP2 load for guide 16 mm (kg) |
|---|---|
| 0.50 | 4059 |
| 0.60 | 3905 |
| 0.70 | 3738 |
| 0.80 | 3563 |
| 0.90 | 3382 |
| 1.00 | 3201 |
| 1.10 | 3023 |
| 1.20 | 2848 |
| 1.32 | 2648 |
| 1.65 | 2156 |
| BP3 tripping speed (m/s) | BP3 load for guide 10 mm (kg) | BP3 load for guide 16 mm (kg) |
|---|---|---|
| 0.50 | 3123 | 3921 |
| 0.60 | 3005 | 3773 |
| 0.70 | 2876 | 3612 |
| 0.80 | 2741 | 3442 |
| 0.90 | 2603 | 3268 |
| 1.00 | 2463 | 3093 |
| 1.10 | 2326 | 2920 |
| 1.20 | 2192 | 2752 |
| 1.32 | 2037 | 2558 |
| 1.65 | 1659 | 2083 |
