Overspeed Governors
LK200 Bidirectional
Compact, dynamic, high-performance and with everything you need.
-(1).png?data=eyJtZWRpYV9pZCI6Mjg0OTUxLCJieXRlcyI6OTg1MzgsInByb2plY3RfaWQiOjY5LCJoYXNfaW1naXgiOjF9)
Overspeed governor LK200 Bidirectional
Bidirectional overspeed governor approved by TÜV Germany according to directive 2014/33/UE and standards EN81-20/50.
Also available in reduced dimensions.
Also available with remote control, rope safety guard, protection cover, encoder, device for protection of uncontrolled car movement and anti-creeping assembled on the top of the governor inside the structure.
| LK200 Bidirectional | |
|---|---|
| Pulley Type | Pulley Ø 200 mm with hardened groove bidirectional with rope diameter 6-6.5 mm |
| Nominal Speed | Up to 1,48 m/s |
| Tripping Speed | From 0,32 m/s up to 1,70 m/s |
| Hardened groove | |
| Certifications | EN81-20/50, 2014/33/EU, Gost TP TC |
| Optional | |
|---|---|
| Test groove | |
| Rope safety guard | |
| Protection cover | |
| Remote control (IP 50) |
|
| Incremental encoder | |
| UCM |
Combinable tension weights
